Cooling Incubator CI-6 Plus, 200L, 5°C-60°C Microprocessor, LED Display

Cooling Incubator CI-6 Plus

Discover the Cooling Incubator CI-6 Plus, specifically designed for precise temperature control ranging from 5°C to 60°C with ±0.5°C accuracy. This model offers a generous 200 litre internal volume. Featuring a microprocessor controller and a 1" - 7 Segment, Big Size LED display (digital LED display generally), it provides user-friendly temperature monitoring. The CI-6 Plus ensures uniform conditions inside the chamber via a powerful fan motor for forced air circulation. It is built with machine filled PUF insulation and a unique design of thermal barrier for better energy efficiency. The unit uses a hermetically sealed Compressor with CFC free refrigerant and requires a VS-02 voltage stabilizer. Comprehensive safety features include a high temperature safety cut off, sensor failure alarm, power failure alarm, door open alarm, and temperature variation alarm. These incubators are suitable for applications in pharmaceutical, microbiology, biotechnology, chemical, and research labs, used for tasks such as culture of bacteria, microorganism, tissue culture, incubation, immunological work, and storage of vaccines. Validation protocols with IQ, OQ, DQ documentation are available as per ICH guidelines. Cooling Incubator CI-6 Plus

Feature	Specification for Cooling Incubator CI-6 Plus	Source(s)
Model	CI-6 Plus
Internal Volume	200 Litres
Number of Trays	2
Internal Dimensions (WxDxH)	660x655x450 mm
External Dimensions (WxDxH)	800x1095x1020 mm
Temperature Range	5°C to 60°C
Temperature Accuracy	± 0.5°C
Temperature Control	Microprocessor with PT-100 sensor
Display	1" - 7 Segment, Big Size LED
Temperature Uniformity	Maintained by powerful fan motor for forced air circulation
Heating	Long life SS tubular heaters
Refrigeration	Hermetically sealed Compressor with CFC free refrigerant
Insulation	Machine filled PUF insulation (70 mm body, 80 mm door minimum), CFC free polyurethane foam
Thermal Barrier	Unique design for better energy efficiency
Power Failure Alarm	Audio Visual Alarm
Door Open Alarm	Audio Alarm (if door open for over one minute)
Temperature Variation Alarm	Set Temperature ± 2°C, Audio Visual Alarm
Sensor Failure Alarm	Yes
High Temp. Safety Cut Off	Yes
Illumination	8 Watts Fluorescent Lamp (Standard Models)
Internal Body Material	Stainless Steel - 304 grade (Standard Models)
External Body Material	Powder Coated CRCA Steel (Standard Models)
Noise Level	Less Than 65 db(A)
Recommended Voltage Stabilizer	VS-02
Electrical	220-240 volts, 50Hz, Single Phase
Validation Protocol	IQ, OQ, DQ Documentation available as per ICH guidelines
