COOLING INCUBATOR REMI CI-12 Plus Capacity 370 liters, Temperature range 5°C to 60°C Microprocessor (VS-03) LCD

₹235,000.00
(No reviews yet)
Condition:
New
Current Stock:
Adding to cart… The item has been added
Description

COOLING INCUBATOR REMI CI-12 Plus

Salient Features
  • Temperature range 5°C to 60°C
  • Unique design of thermal barrier for better energy efficiency
  • Machine filled CFC free PUF insulation to eliminate void pockets
  • Powerful fan motor for forced air circulation to maintain uniform conditions inside chamber
  • Heating by long life SS tubular heaters
  • Chamber calibration port on side
  • Adjustable trays
  • Hermetically sealed Compressor with CFC free refrigerant
  • High temperature safety cut off & alarms for high / low set parameters
  • Sensor failure alarm
  • Electrical circuit breaker
  • Time delay for compressor switch on
  • Overload cut off relay for compressor
  • Rounded inner chamber for easy cleaning
  • Attractive door profile
  • Microprocessor controller with LED display of Temperature with set, process value & audio visual alarm (standard)
  • Weight carrying capacity of each tray: 15 Kg uniformly distributed.
  • Auto door closer.
  • Smart Handle with LED door closure indication.
  • Optional
    • 4″ LCD display with additional features (Details overleaf)
    • Touch screen display ( TFT ) with additional features(Details overleaf)
    • Validation protocol with IQ, OQ, PQ Documentation
    • Port for calibration probes / safety back up

LCD Display COOLING INCUBATOR REMI CI-12 Plus

Features
  • 4 Inch attractive LCD display
  • Intelligent Controller helps maintain temperature in case of sensor failure
  • Battery Backup for Temperature Controller
  • Auto tuning of controller
  • Self-Diagnosis for errors COOLING INCUBATOR REMI CI-12 Plus
  • Histogram format of 24 hours temperature recording
  • Settable High / low alarm points
  • Memory for storage of upto 1000 records
  • Centronic interface to record Temperature, Date, & Time by attaching Dot Matrix printer with adjustable print interval
  • Alarm on equipment / output for remote alarm
  • Cyclic Transfer (Optional)

REMI ‘Data Soft’

Features
  • Multiple level alpha numerical password with password ageing
  • Secured audit trail report COOLING INCUBATOR REMI CI-12 Plus
  • Alarm report with mention of alarm condition
  • Mean Kinetic Temperature able to be calculated for any days& alarm deviation report
  • Reports in graphical and tabular form
  • Data Stored in PC server with Lan connectivity and can be monitored on PC with password authentication
  • Multi chamber data acquisition on single software
  • Communication through RS 485 / TCP IP
  • Power failure and resumption recorded with date and time

Touch Screen Display

Features
  • 7 inch big colour touch screen COOLING INCUBATOR REMI CI-12 Plus
  • PLC (Programable logic controller)
  • Memory of 10,000 records
  • Centronic interface to record Temperature, Date & Time by attaching Dot Matrix printer with adjustable print interval
  • Ethernet port
  • Battery backup in case of power failure for display, alarms & off-line data logging (optional)
  • Programmable cyclic timer for controlling illumination conditions
  • Remi Datasoft Data acquisition software complying to 21 CFR part 11 as per USFDA Guidelines (optional)

Optional Accessories COOLING INCUBATOR REMI CI-12 Plus

To be Ordered Separately
  • Chamber illumination with the help of 2 Nos. fluorescent tubes
  • Chamber illumination with 2 Nos. ultra violet lights
  • 24 hours Cyclic Timer for regulating illumination conditions
  • Data logger for 8 Point temperature recording with sensor printer interface and software
  • Software as per 21 CFR Part 11 requirements
  • PLC Based Control System with HMI Touch Screen
  • Biometrics Magnetic Door Access for Secured Door opening with software to maintain log
  • Validation (mapping) consist of one cycle for temperature at any one set point for 24 hours on empty and loaded condition
  • Standby Refrigeration System
  • GSM alert through SIM card
