Digital Melting and Boiling Point Apparatus

Digital Melting and Boiling Point Apparatus

Product Description: Digital Melting and Boiling Point Apparatus The Digital Melting / Boiling Point Apparatus series (Sky-201, Sky-202, Sky-203) are compact instruments designed for the accurate determination of melting points of solid samples and boiling points of liquid samples.

• Sky-201: This is a basic model featuring a thermometer for temperature reading. It has a glare-free background LED light with adjustable light intensity. Digital Melting and Boiling Point Apparatus
• Sky-202: This model features a covered cylindrical Silicon Oil Bath for operator safety and a built-in magnetic stirrer with electronic speed controller. It has an electronic controller for adjusting the heating rate and a 3 Digit LED display of temperature with a PT-100 Sensor. It also includes a glare-free background LED light with adjustable light intensity and a provision for holding the melting point display when the sample melts.
• Sky-203: Similar to the Sky-202, this model also has a covered cylindrical Silicon Oil Bath, a built-in magnetic stirrer with electronic speed controller, and an electronic controller for adjusting the heating rate. It features a more precise 4 Digit LED display of temperature with a PT-100 Sensor. It also has a glare-free background LED light with adjustable light intensity and a hold facility for the melting point display. Additionally, it includes a built-in image magnifier for a clear vision of the sample.

Specifications: Digital Melting and Boiling Point Apparatus

Specification	Sky-201	Sky-202	Sky-203
Temperature Range	2nd above RT - 250°C	2nd above RT - 300°C	2nd above RT - 300°C
Readability	1	1	0.1
Display Type	Thermometer	3 Digit LED	4 Digit LED
Display Parameter	NA	Temperature	Temperature
Inbuilt Stirrer	NA	Yes	Yes
Heating Rate Control	Electronic Low/High	Electronic	Electronic
Stirrer Speed Control	NA	NA	NA
Temperature Sensor	NA	PT-100	PT-100
Back-ground Light	Yes, variable Intensity	Yes, variable Intensity	Yes, variable Intensity
Hold Facility	NA	Yes	Yes
Standard Accessories	Magnetic Rotor, Oil jar Heating assembly, Silicon oil, Set of 100 capillaries, Temperature probe	Magnetic Rotor, Oil jar Heating assembly, Silicon oil, Set of 100 capillaries, Temperature probe	Magnetic Rotor, Oil jar Heating assembly, Silicon oil, Set of 100 capillaries, Temperature probe

Frequently Asked Questions: Digital Melting and Boiling Point Apparatus

• What is the primary use of these Melting / Boiling Point Apparatus? These instruments are designed for the accurate determination of melting points of solid samples and boiling points of liquid samples.
• What is the temperature range of the Sky-201 model? The temperature range for the Sky-201 is 2nd above Room Temperature (RT) to 250°C.Digital Melting and Boiling Point Apparatus
• What is the temperature range for the Sky-202 and Sky-203 models? Both the Sky-202 and Sky-203 have a temperature range of 2nd above Room Temperature (RT) to 300°C.
• What type of temperature display does the Sky-201 have? The Sky-201 uses a thermometer for temperature reading.
• What type of temperature display do the Sky-202 and Sky-203 have? The Sky-202 has a 3 Digit LED display, while the Sky-203 has a more precise 4 Digit LED display. Both use a PT-100 Sensor.
• Do the Sky-202 and Sky-203 models have a stirrer? Yes, both models feature a built-in magnetic stirrer with an electronic speed controller.
• Can the heating rate be controlled on these apparatus? Yes, the Sky-202 and Sky-203 have an electronic controller for adjusting the heating rate. The Sky-201 also has an electronic Low/High heating rate control.
• Do these apparatus have a safety feature? The Sky-202 and Sky-203 are equipped with a covered cylindrical Silicon Oil Bath for operator safety.
• Is there a way to note the melting point once it's observed? Yes, the Sky-202 and Sky-203 have a provision or facility to hold the melting point display when the sample melts.
• What standard accessories are included with these apparatus? Each model comes with a Magnetic Rotor, Oil jar Heating assembly, Silicon oil, a Set of 100 capillaries, and a Temperature probe.
• Does the Sky-203 have any unique features? Yes, the Sky-203 includes a built-in image magnifier for a clearer view of the sample. Digital Melting and Boiling Point Apparatus
• Are these apparatus suitable for determining boiling points? Yes, these are designed for determining both melting points of solid samples and boiling points of liquid samples.
