ESICO 1760 Microprocessor KF Moisture Titrator

ESICO 1760 Microprocessor KF Moisture Titrator

The ESICO 1760 Microprocessor Karl Fischer Moisture Titrator represents the finest volumetric titration system available for precise moisture content analysis. Manufactured by Environmental and Scientific Instruments Co. (ESICO), an ISO 9001:2000 certified company, this advanced laboratory instrument utilizes cutting-edge microcontroller technology to deliver superior accuracy and reproducibility in moisture determination for liquids, powders, fine particles, and fiber samples.

Key Features & Benefits

• Precision Moisture Measurement - Accurately determines moisture content from 10 ppm to 100%
• Multiple Result Formats - Automatically calculates and displays moisture in ppm, percentage, and mg H₂O
• Advanced Dispensing System - Highly sensitive motorized dispensing eliminates conventional glass burettes
• Fine Resolution - Precise 0.01 ml titrant dispensing resolution for accurate results
• Automated Titer Calculation - Built-in facility for automatic KF reagent titer factor calculation
• Clear End-Point Detection - Visual LED indicator and audible alarm signal when end point is reached
• Adjustable Parameters - Customizable wait time (1-59 seconds) for end point confirmation
• User-Friendly Interface - 24 soft-touch membrane keys with complete numeric keypad
• Data Storage - Stores date, time, batch number, and results for up to 20 titrations
• Battery Backup - Retains stored data for at least one month even when powered off
• Integrated Functions - Built-in magnetic stirrer with adjustable speed and internal clock
• Printer Compatibility - External printer interface for documentation of results
• Complete Kit - Includes all necessary accessories for immediate operation
• 1-Year Warranty - Manufacturer-backed quality assurance

Technical Specifications

Parameter	Specification
Model	ESICO 1760
Measuring Range	10 ppm to 100% moisture
Measuring Method	Karl Fischer volumetric titration
Dispensing System	Highly sensitive motorized system
Titrant Volume Resolution	0.01 ml
Titrant Volume Indication	0.00 to 99.99 ml on display
Moisture Content Calculation	Percentage: 0.00 to 100% PPM: 10 to 999999 mg H₂O: 0.00 to 999.99
KF Titer Factor	In-built automatic calculation facility
End Point Indication	Visual LED and audible alarm
Wait Time for End Point	Adjustable (1 to 59 seconds)
Dispensing Pump Calibration	Available through keyboard
Keyboard	24 keys, soft touch, membrane type
Sample Storage	Up to 20 latest samples using FIFO memory
Display	8-digit bright red, seven-segment LED display
Clock	In-built clock with date and time display
Stirrer	In-built magnetic stirrer with adjustable speed
Reagent Bottles	3 x 250 ml bottles for KF Reagent, Methanol & Calcium Chloride
Printer Interface	External dot-matrix printer interface available
Power	230V AC ± 10%, 50 Hz
Dimensions	L 360 x B 295 x H 175 mm (Approx.)

Applications

The ESICO 1760 KF Moisture Titrator is designed for precise moisture content analysis across a wide range of industries and sample types:

Pharmaceutical Industry

• Raw Material Testing - Verify moisture content in active pharmaceutical ingredients and excipients
• Quality Control - Ensure finished products meet moisture specifications
• Stability Studies - Monitor moisture changes during product shelf-life studies
• Research & Development - Support formulation development with accurate moisture determination

Food & Beverage Industry

• Ingredient Analysis - Test moisture levels in food additives and ingredients
• Product Quality - Verify moisture content in finished food products
• Shelf-Life Studies - Monitor moisture stability during storage
• Oil & Fat Testing - Determine water content in oils and fats

Chemical Manufacturing

• Raw Material Verification - Confirm moisture specifications of incoming materials
• Process Control - Monitor moisture during chemical production processes
• Quality Assurance - Ensure final products meet moisture requirements
• Solvent Analysis - Determine water content in organic solvents

Other Applications

• Petrochemical Analysis - Measure water in petroleum products
• Cosmetics Testing - Verify moisture content in creams, lotions, and powders
• Plastic & Polymer Testing - Determine moisture in plastic resins and additives
• Environmental Testing - Analyze water content in soil and environmental samples

Operating Principle

The ESICO 1760 utilizes the Karl Fischer volumetric titration method, a highly specific technique for water determination. This method is based on the Bunsen reaction between iodine and sulfur dioxide in an aqueous medium. The titrator precisely dispenses the Karl Fischer reagent until all water in the sample is consumed, as indicated by the appearance of excess iodine at the endpoint.

The microprocessor-controlled system accurately measures the volume of titrant dispensed and automatically calculates the moisture content based on the sample weight, titrant volume, and titer factor. This eliminates manual calculations and potential human error, providing reliable and reproducible results.

Advanced Features Explained

Motorized Dispensing System ESICO 1760 Microprocessor KF Moisture Titrator

The ESICO 1760 features a highly sensitive motorized dispensing system that replaces conventional glass burettes and plunger systems. This innovation offers several advantages:

• Enhanced Precision - Delivers titrant in precise 0.01 ml increments for accurate results
• Improved Reliability - Eliminates the fragility concerns of glass burettes
• Consistent Delivery - Provides uniform titrant flow for reproducible results
• Simple Operation - Automates the titration process for ease of use

Automated Titer Factor Calculation ESICO 1760 Microprocessor KF Moisture Titrator

The built-in titer factor calculation feature simplifies a critical aspect of Karl Fischer titration:

• Automatic Calculation - Determines titer factor without manual calculations
• Repeated Averaging Method - Ensures the most accurate titer value
• Simplified Standardization - Makes reagent standardization quick and reliable
• Improved Accuracy - Reduces potential for human error in titer determination

Comprehensive Data Management ESICO 1760 Microprocessor KF Moisture Titrator

The ESICO 1760 offers robust data handling capabilities:

• Result Storage - Retains data for up to 20 titrations using FIFO (First In, First Out) method
• Complete Record Keeping - Stores date, time, batch number, and final results
• Non-Volatile Memory - Battery backup maintains stored data for at least one month
• Documentation Options - External printer interface for hard copy records

Standard Accessories ESICO 1760 Microprocessor KF Moisture Titrator

The ESICO 1760 KF Moisture Titrator comes complete with all necessary accessories for immediate operation:

• Dual Platinum Electrode - For precise endpoint detection
• Titration Vessel - Specialized glassware for KF titration
• Built-in Magnetic Stirrer - With adjustable speed control
• Teflon Coated Magnetic Stirring Capsule - For effective sample mixing
• Reagent Bottles
  • 250 ml Bottle for Methanol
  • 250 ml Reservoir Bottle for KF Solution
  • 250 ml Bottle for Calcium Chloride
• 25 μl Syringe - For precise sample introduction
• Adapters ESICO 1760 Microprocessor KF Moisture Titrator
  • Adapter for KF Reservoir
  • Adapter for acetone Reservoir Bottle
• Tubing Sets
  • Set of Dispenser Tubes
  • Set of Connecting Tubes
• Main Lead - Power connection cable
• Instruction Manual - Comprehensive user guide

All components are securely packaged in shock-proof Styrofoam packing inside an attractive and durable storage box.

Why Choose the ESICO 1760?

Superior Accuracy & Precision ESICO 1760 Microprocessor KF Moisture Titrator

The ESICO 1760 delivers exceptional measurement precision with its 0.01 ml resolution dispensing system and comprehensive moisture calculation capabilities. The automated titer factor calculation and precise endpoint detection ensure reliable results for even the most demanding applications.

User-Friendly Design ESICO 1760 Microprocessor KF Moisture Titrator

From its intuitive membrane keypad to the bright LED display, every aspect of the ESICO 1760 is designed for ease of operation. The numeric keypad simplifies data entry, while the built-in magnetic stirrer and automated calculations streamline the titration process.

Versatile Applications ESICO 1760 Microprocessor KF Moisture Titrator

With its wide measurement range (10 ppm to 100% moisture) and ability to analyze various sample types, the ESICO 1760 is suitable for diverse applications across pharmaceutical, food, chemical, and other industries. This versatility makes it an invaluable tool for any laboratory requiring moisture content determination.

Quality Assurance ESICO 1760 Microprocessor KF Moisture Titrator

Manufactured by an ISO 9001:2000 certified company, the ESICO 1760 is built to high-quality standards. The 1-year warranty provides additional peace of mind, while the durable construction ensures reliable performance over years of laboratory use.

About ESICO ESICO 1760 Microprocessor KF Moisture Titrator

Environmental and Scientific Instruments Co. (ESICO) is an ISO 9001:2000 certified manufacturer specializing in laboratory and analytical instruments. With a comprehensive product range including spectrophotometers, flame photometers, pH meters, and various other laboratory equipment, ESICO is committed to providing high-quality instrumentation for scientific research, quality control, and educational applications.

Additional Products from ESICO ESICO 1760 Microprocessor KF Moisture Titrator

The company offers a wide range of analytical and laboratory equipment, including:

• Semi Auto Analyzers
• Single Beam and Double Beam UV/VIS Spectrophotometers
• Flame Photometers
• Haemoglobin Meters
• Digital pH Meters
• Digital Photo Fluorometers
• Digital Conductivity Meters
• Turbidity Meters
• Digital DO Meters
• Digital TDS Meters
• Temperature Indicators
• Digital Telethermometers
• Water & Soil Analysis Kits
• Digital Salinity Meters
• Digital Colony Counters
• Portable Test Meters
• Pharmaceutical Testing Equipment
• Various Laboratory Microscopes

Summary ESICO 1760 Microprocessor KF Moisture Titrator

The ESICO 1760 Microprocessor KF Moisture Titrator represents the pinnacle of volumetric Karl Fischer titration technology. With its advanced motorized dispensing system, comprehensive moisture calculation capabilities, and user-friendly interface, this instrument delivers the precision and reliability required for critical moisture analysis applications.

[section] [title text="ACCESSORIES"]

Karl Fisher Titrator Spare Dual Platinum Electrode Model 1760	₹ 15,000.00
Karl Fisher Titrator Spare Titration vessel Model 1760	₹ 6,600.00
Karl Fisher Titrator Spare Reservoir Bottle clear glass (500ml) Model 1760	₹ 3,500.00
Karl Fisher Titrator Spare Moisture trap Model 1760	₹ 900.00
Karl Fisher Titrator Spare Reagent Tube Black set of 2 Each 75cm Model 1760	₹ 1,750.00
Karl Fisher Titrator Spare Dispensing Tube Red COLOR set of 2 size 4 " each Model 1760	₹ 1,750.00

[/section]
