The Lutron GC-2028 is a professional-grade carbon dioxide and temperature measuring instrument featuring advanced NDIR (Non-Dispersive Infrared) technology for highly accurate CO2 monitoring. ISO-9001 and CE certified, this precision device provides reliable measurements for indoor air quality assessment, HVAC system verification, and environmental monitoring applications.

Key Features & Benefits

• NDIR Measurement Technology - Ensures accurate, stable CO2 readings for long-term operation
• High Precision CO2 Detection - Measures from 0 to 4,000 ppm with ±40 ppm accuracy (≤1,000 ppm)
• Integrated Temperature Monitoring - Measures from 0°C to 50°C (32°F to 122°F)
• Separate Probe Design - Convenient for remote measurements in hard-to-reach areas
• CO2 Alarm Function - Programmable threshold alerts for exceeding CO2 limits
• Data Management - Records maximum and minimum readings with recall capability
• Large S-TN LCD Display - High contrast screen (52mm × 38mm) for excellent readability
• Data Hold Function - Freezes current readings for convenient recording
• Dual Computer Interface - Both RS232 and USB connectivity options for data transfer
• Altitude Compensation - Adjustable settings for accurate readings up to 9,000 meters
• Automatic Temperature Compensation - Ensures accurate CO2 readings across temperature ranges
• Intelligent Power Management - Auto shut-off feature to extend battery life
• Dual Power Options - Operates on batteries or AC adapter (DC 9V)
• Portable Design - Includes hard carrying case for field measurements and transportation

Technical Specifications

CO2 (Carbon Dioxide) Measurement

Parameter	Specification
Measurement Range	0 to 4,000 ppm
Resolution	1 ppm
Accuracy	±40 ppm (≤1,000 ppm) ±5% of reading (>1,000 ppm to ≤3,000 ppm) ±250 ppm typically (>3,000 ppm, reference only)
Repeatability	±20 ppm (≤3,000 ppm)
Response Time	<2 minutes typically (to 63% of reading value)
Temperature Compensation	Automatic
Altitude Compensation Setting	0 to 9,000 meters

Temperature Measurement

Parameter	Specification
Measurement Range	0°C to 50°C (32°F to 122°F)
Resolution	0.1 degree
Accuracy	±0.8°C (±1.5°F)

General Specifications

Parameter	Specification
Display	52 mm × 38 mm dual function LCD with high contrast
Circuit	Custom one-chip microprocessor LSI circuit
Sampling Time	Approximately 1 second
Data Output	RS232/USB PC serial interface
Power Supply	DC 1.5V battery (UM3, AA) × 6 PCs or equivalent Alternative: DC 9V adapter (optional)
Power Consumption	Approx. DC 9.6 mA (90% period) Approx. DC 128 mA (10% period)
Operating Temperature	0°C to 50°C
Operating Humidity	Main instrument: Less than 85% RH CO2 probe: Less than 85% RH
Advanced Settings	CO2 altitude value adjustment CO2 alarm threshold Temperature unit selection (°C/°F) Auto power off enable/disable

Physical Specifications Lutron GC-2028 NDIR CO2 Meter

Parameter	Specification
Dimensions (Main Unit)	173 × 68 × 42 mm (7.9 × 2.7 × 1.2 inches)
Dimensions (CO2 Probe)	185 × 38 × 26 mm
Weight (Main Unit)	372 g / 0.82 LB (including batteries)
Weight (CO2 Probe)	158 g / 0.35 LB

Applications Lutron GC-2028 NDIR CO2 Meter

The Lutron GC-2028 is designed for a wide range of professional applications:

• Indoor Air Quality (IAQ) Assessment - Monitor CO2 levels in offices, schools, and public buildings
• HVAC System Verification - Confirm proper ventilation and air exchange rates
• Greenhouse Monitoring - Optimize CO2 levels for plant growth and productivity
• Industrial Hygiene - Ensure safe working conditions in manufacturing facilities
• Laboratory Environment Control - Maintain precise atmospheric conditions
• Building Management - Assess ventilation effectiveness in commercial structures
• Classroom and Meeting Room Monitoring - Ensure adequate ventilation for cognitive function
• Healthcare Facilities - Monitor air quality in patient care environments
• Environmental Research - Collect field data for scientific studies
• High-Altitude Applications - Accurate readings with altitude compensation up to 9,000 meters

Understanding CO2 Measurement Lutron GC-2028 NDIR CO2 Meter

Carbon dioxide (CO2) concentration is a critical indicator of air quality and ventilation effectiveness. The GC-2028 uses advanced NDIR technology, which provides several advantages over other sensing methods:

• Superior Accuracy - NDIR technology directly measures CO2 absorption in the infrared spectrum
• Long-Term Stability - Minimal drift in readings over extended periods of operation
• Specificity - Selectively measures CO2 without interference from other gases
• Durability - Robust sensor design for reliable operation in various environments

Typical CO2 concentration levels and their significance:

• 400-600 ppm - Fresh outdoor air levels
• 600-1,000 ppm - Acceptable indoor air quality
• 1,000-2,000 ppm - Complaints of drowsiness and poor air quality
• 2,000-5,000 ppm - Headaches, sleepiness, poor concentration, increased heart rate
• >5,000 ppm - Workplace exposure limit in many jurisdictions

Advanced Features Explained Lutron GC-2028 NDIR CO2 Meter

Altitude Compensation

CO2 measurements are affected by atmospheric pressure, which changes with altitude. The GC-2028's altitude compensation feature (adjustable from 0 to 9,000 meters) ensures accurate readings regardless of elevation by automatically adjusting calculations based on the programmed altitude value.

Data Management

The instrument's memory function records maximum and minimum values, allowing users to track fluctuations in CO2 levels over time. This is particularly valuable for assessing ventilation performance and identifying peak concentration periods.

Computer Connectivity

With both RS232 and USB interface options, the GC-2028 can connect to computers for data logging, analysis, and report generation. When paired with the optional SW-U801-WIN data acquisition software, users can create comprehensive records of CO2 and temperature measurements for compliance documentation or trend analysis.

Package Contents Lutron GC-2028 NDIR CO2 Meter

• GC-2028 Main Instrument
• CO2/Temperature Probe
• Hard Carrying Case
• Instruction Manual

Optional Accessories Lutron GC-2028 NDIR CO2 Meter

• RS232 Cable (UPCB-02)
• USB Cable (USB-01)
• Data Acquisition Software (SW-U801-WIN)
• AC/DC 9V Adapter (not included, available separately)

Certification & Quality Lutron GC-2028 NDIR CO2 Meter

The Lutron GC-2028 is manufactured under ISO-9001 quality management standards and meets CE certification requirements and IEC1010 safety standards. These certifications ensure reliable performance and accurate measurements for professional and scientific applications.

Why Choose the Lutron GC-2028? Lutron GC-2028 NDIR CO2 Meter

• Superior NDIR Technology - More accurate and stable than electrochemical CO2 sensors
• Professional-Grade Accuracy - Precise measurements for critical applications
• Versatile Application Range - From standard indoor environments to high-altitude locations
• Comprehensive Data Management - Record, recall, and transfer measurement data
• Portable Field-Ready Design - Complete with carrying case for on-site measurements
• Separate Probe Design - Allows measurements in confined or difficult-to-access areas
• Quality Certifications - ISO-9001, CE, and IEC1010 compliance for reliability

The Lutron GC-2028 NDIR CO2 Meter provides professionals with a reliable, accurate, and versatile instrument for measuring carbon dioxide concentrations and temperature in a wide range of environments. Its advanced features, portable design, and robust construction make it an ideal choice for air quality assessment, ventilation verification, and environmental monitoring applications.
