AQUASOL TABLE TOP MULTI-PARAMETER MODEL ABTDS01 RANGE PH 02-16/ORP +- 1999MV /COND- 0-100 MS/ TDS 0-66 PPTSALINITY 0-50PPT/TEMP 0-110C WITH BUILT IN STIRRER MICROPROCESSER USB CONNECTIVITY WITH SOFTWARE
AQUASOL ABTDS01 Table Top Multi-Parameter Meter with Built-in Stirrer
The AQUASOL ABTDS01 Table Top Multi-Parameter Meter is a high-precision laboratory analytical workstation engineered for advanced water quality analysis, chemical testing, industrial process monitoring, and research laboratory applications. Designed for modern laboratories requiring multiple analytical capabilities within a single platform, this versatile benchtop instrument accurately measures pH, ORP (mV), Conductivity, TDS, Salinity, and Temperature with exceptional reliability and repeatability.
Powered by an advanced microprocessor-based control system, the ABTDS01 delivers stable and highly accurate measurements across broad analytical ranges. Its integrated built-in magnetic stirrer with variable speed control ensures consistent sample homogeneity, enabling faster stabilization times and improved measurement precision during pH and conductivity testing procedures.
The instrument features a large digital display with intuitive keypad operation for simplified calibration, parameter selection, and real-time monitoring. Automatic Temperature Compensation (ATC) further enhances analytical accuracy by automatically correcting temperature-sensitive measurements during laboratory workflows.
Built for professional laboratory environments, the AQUASOL ABTDS01 includes USB connectivity with dedicated PC software for seamless data logging, storage, analysis, and report generation. This enables efficient GLP-compliant documentation and improves traceability for quality control, environmental monitoring, pharmaceutical testing, biotechnology research, food processing, aquaculture, and educational laboratory applications.
The complete system includes pH electrode, conductivity probe, temperature sensor, electrode holder, software interface, and power adapter, making the ABTDS01 a complete multi-parameter laboratory solution for demanding analytical applications.
Technical Specifications
| Parameter / Feature | Details |
|---|---|
| Product Model | AQUASOL ABTDS01 |
| Product Type | Table Top Multi-Parameter Meter with Built-in Stirrer |
| Measured Parameters | pH, ORP (mV), Conductivity, TDS, Salinity, Temperature |
| pH Range | -2.00 to 16.00 pH |
| ORP Range | ±1999 mV |
| Conductivity Range | 0 to 100 mS/cm (Auto-ranging) |
| TDS Range | 0 to 66 ppt |
| Salinity Range | 0 to 50 ppt |
| Temperature Range | 0 to 110°C |
| Temperature Compensation | Automatic Temperature Compensation (ATC), 0 to 100°C |
| Control System | Microprocessor-Based Technology |
| Display Type | Large Digital Display with Mode Indicators |
| Stirrer Type | Built-in Magnetic Stirrer with Variable Speed Control |
| Data Output | USB Port with PC Software |
| Power Supply | AC Power Adapter |
| Included Accessories | pH Electrode, Conductivity Probe, Temperature Probe, Electrode Holder, USB Cable, PC Software |
| Application Areas | Water Quality Analysis, Industrial Testing, Pharmaceutical Labs, Biotechnology Research, Aquaculture, Educational Laboratories |
Core Features & User Benefits
The AQUASOL ABTDS01 Multi-Parameter Meter is engineered to provide comprehensive analytical performance, data accuracy, and operational efficiency for demanding laboratory applications.
- Multi-Parameter Analytical Capability Simultaneously supports pH, ORP, conductivity, TDS, salinity, and temperature measurements, reducing the need for multiple laboratory instruments and improving workflow efficiency.
- Integrated Magnetic Stirrer The built-in variable speed magnetic stirrer ensures uniform sample mixing for faster stabilization, enhanced measurement consistency, and improved analytical accuracy.
- Advanced Microprocessor Technology Microprocessor-controlled operation delivers stable readings, precise measurement performance, and excellent repeatability for professional laboratory analysis.
- Automatic Temperature Compensation Integrated ATC functionality automatically corrects temperature-sensitive measurements, ensuring highly reliable conductivity and pH analysis across varying sample conditions.
- Wide Analytical Measurement Ranges Broad parameter ranges allow the instrument to analyze purified water, industrial samples, chemical solutions, saline samples, environmental water, and laboratory process fluids.
- USB Data Logging & PC Connectivity USB communication with dedicated software simplifies data transfer, result storage, report generation, and GLP-compliant laboratory documentation.
- User-Friendly Laboratory Interface Large digital display and intuitive keypad controls provide simplified calibration, parameter selection, and operational convenience for laboratory personnel.
- Complete Laboratory Testing Solution Supplied with all essential probes, electrodes, software, and accessories, enabling immediate deployment for advanced analytical testing applications.
- Versatile Laboratory Applications Ideal for environmental monitoring, industrial quality control, pharmaceutical testing, aquaculture analysis, food processing, and educational laboratory research.
Frequently Asked Questions (FAQ)
What parameters can the AQUASOL ABTDS01 Multi-Parameter Meter measure?
The AQUASOL ABTDS01 measures multiple laboratory parameters including pH, ORP (mV), conductivity, TDS, salinity, and temperature within a single compact benchtop instrument. This allows laboratories to perform comprehensive water and solution analysis without requiring multiple separate devices.
The instrument is suitable for environmental analysis, industrial testing, chemical laboratories, pharmaceutical applications, aquaculture monitoring, and educational laboratory research.
What is the advantage of the built-in magnetic stirrer?
The integrated magnetic stirrer ensures proper sample homogeneity during analysis, improving measurement stability and reducing response time for pH and conductivity testing applications.
Variable speed control allows laboratory users to optimize stirring intensity based on sample type, improving repeatability and analytical accuracy for sensitive laboratory measurements.
Does the AQUASOL ABTDS01 support data logging and computer connectivity?
Yes, the AQUASOL ABTDS01 includes USB connectivity and dedicated PC software for efficient data transfer, logging, result analysis, and report generation.
This feature supports GLP-compliant documentation, long-term data storage, and simplified laboratory record management for quality assurance and research applications.
What is Automatic Temperature Compensation (ATC)?
Automatic Temperature Compensation (ATC) automatically adjusts pH and conductivity measurements according to sample temperature changes, ensuring accurate analytical results across varying laboratory conditions.
This functionality significantly improves reliability during conductivity and pH measurements where temperature fluctuations can influence analytical accuracy.
Which industries commonly use the AQUASOL ABTDS01 Multi-Parameter Meter?
The AQUASOL ABTDS01 is widely used in water quality laboratories, environmental monitoring facilities, pharmaceutical manufacturing, biotechnology research, aquaculture systems, food and beverage production, chemical industries, and educational institutions.
Its broad analytical capabilities and advanced measurement functions make it suitable for both routine laboratory testing and advanced scientific research applications.
