Product Overview:
The EI-DVI Serological Water Bath is a dependable and robust double-walled unit, specifically designed for essential laboratory procedures such as bacteriological and serological tests, incubation, and inactivation. This 'Plain' model utilizes an Energy Regulator control system for temperature management.
Built for longevity and thermal efficiency, the unit is constructed with a high-quality stainless steel inner chamber and durable powder-coated exterior. It is available in multiple capacities to accommodate varying testing needs, from single racks to four racks.
Key Applications:
Serological Water Baths are essential for versatile clinical and research procedures. Applications include:
• Bacteriological and serological tests.
• Incubation of cultures.
• Agglutination.
• Inactivation processes, such as the Washerman Kolmer and Khan Test inactivation.
• Pharmaceutical and biomedical procedures.
Construction and Design:
Double-Walled Construction: The water bath features a double-walled design. The interior chamber is manufactured from HIGHLY POLISHED STAINLESS STEEL (S.S. sheet), ensuring resistance to corrosion and easy cleaning.
Exterior: The outer body is made of Mild Steel Sheet (M.S.) which is finished with a durable powder coating. Insulation: The gap between the inner and outer walls is filled with special-grade insulating material, such as glass wool, to minimize thermal losses and ensure efficient heating.
Heating Element and Tray: The inner chamber houses an immersion-type heating element. This element is protected by a perforated, removable diffuser shelf or tray, ensuring uniform heating distribution throughout the chamber.
Lid and Drain: A stainless steel cover is provided as a standard accessory. The unit is also provided with a drain plug to facilitate hassle-free emptying and cleaning of the inner chamber.
Temperature Control System:
This model is controlled via a capillary type thermostat and Energy Regulator, providing reliable heating performance.
Temperature Range: Typically ranges from ambient +5°C up to 100°C.
Temperature Control: The temperature is controlled by an 'IMPORTED' capillary type THERMOSTAT.
Accuracy: The temperature accuracy is typically around $\pm 1^\circ\text{C}$.
Power Supply: The unit operates on 220/230 Volts AC, 50Hz single phase supply.
Specifications (EI-DVI Brand – Plain Model with Energy Regulator):
This Serological Water Bath is available in multiple standard sizes based on rack capacity.
Please note: Test tube racks are not included with the unit.
|
Rack Capacity
|
Inner Chamber W × D × H (cms)
|
Heating Wattage
|
Control Type
|
Notes
|
|
Single Rack
|
18 x 18 x 13
|
N/A (Standard Rating)
|
Energy Regulator
|
Plain Model
|
|
2 Racks
|
25 x 17.5 x 17.5
|
500 watts
|
Energy Regulator
|
|
|
4 Racks
|
35 x 20 x 17.5
|
1000 watts
|
Energy Regulator
|
Optional Accessories (Available Separately):
For enhanced functionality, optional accessories are available:
• Stirrer Arrangement: A stirrer unit fitted with a 1/20 H.P. high-speed motor, stainless steel stirring rod, and blade can be added for superior temperature uniformity.
• Digital Temperature Control: Though this model is Thermostatic/Energy Regulator controlled, alternatives often include a Digital temperature indicator-cum-controller or a Microprocessor PID digital temperature indicator-cum-controller.
• Low Water Level Cut-Off: An automatic device to prevent damage to the heating element if the water level drops below a safe point.
• Test Tube Racks: Test tube racks are not included with the standard unit and can be provided on requirement.
