Product Description:
Overview: The Next Generation Waterproof ORP Tester:
The Eutech ORPTestr 10 is a reliable, microprocessor-based Oxidation Reduction Potential (ORP) pocket meter designed for quick checking and optimum performance in harsh field conditions. This advanced tester provides up to ±2 mV accuracy across its wide measurement range. Its durable, reinforced engineering plastic sensor casing ensures outstanding physical and chemical durability.
Key Features and Design:
Superior Measurement Performance The meter features a Wide Platinum Band Sensor, providing quick, stable, and repeatable response results, while minimizing contamination due to its larger surface area. Advanced microprocessor technology delivers accuracy up to ±2 mV across the entire range of -999 to 1000 mV.
Enhanced Durability and Maintenance The ORPTestr 10 boasts a Waterproof Design with an IP67 rating, ensuring the integrity of the housing is maintained even in wet or harsh environments. For cost efficiency and extended life, the unit utilizes a User-Replaceable Sensor which requires no tools or messy soldering for replacement. The Double Junction Sensor construction minimizes reference element poisoning, resulting in a significantly longer electrode life, especially when dealing with harsh chemicals.
Intuitive Operation and Efficiency The large Dual Display LCD Screen provides enhanced readability, showing measurement values alongside important meter information such as mode and battery level. Standardisation is quick and easy using the Push-Button Offset Adjustment, allowing adjustment up to ±150 mV to match a known work standard. To conserve battery life and save money, the Auto-Power Off function activates after 8.5 minutes of non-use. The meter also includes a Hold Function to freeze measured values momentarily for easy reading and recording, particularly useful in dimly lit or confined areas.
Data Integrity Critical calibration data is protected by Non-Volatile Memory (EEPROM), which retains all vital information even when the meter is powered off or batteries are changed. The meter also offers Self-Diagnostic capabilities, displaying message codes for easy troubleshooting.
Technical Specifications:
|
Parameter
|
Detail
|
|
Model Name
|
ORPTestr 10 / ORPTEST10
|
|
Brand
|
Eutech
|
|
Measurement Range (ORP)
|
-999 mV to +1000 mV
|
|
Resolution
|
1 mV
|
|
Accuracy
|
±2 mV
|
|
Calibration Points
|
1 (Offset adjustment up to ±150 mV)
|
|
Water Resistance Rating
|
IP67 (Waterproof, Dustproof Housing)
|
|
Display Type
|
Large Dual Custom LCD Display (with battery indicator and error messages/codes)
|
|
Sensor Type
|
Wide Platinum Band, Double Junction, Ag/AgCl System with Polymer Gel
|
|
Sensor Replacement
|
User-Replaceable Sensor
|
|
Special Functions
|
Hold Function, Self-diagnostic, Auto-Power Off (after 8.5 minutes)
|
|
Memory
|
Non-Volatile Memory Backup (EEPROM)
|
|
Power Requirement
|
4 x 1.5V alkaline button cell batteries (“A 76” micro Alkaline)
|
|
Battery Life
|
More than 500 hours
|
|
Operating Temperature
|
0 – 50 °C
|
|
Meter Dimensions
|
16.5 cm x 3.8 cm
|
|
Body Material
|
High Strength Engineering Plastic
|
Primary Applications:
The Eutech ORPTestr 10 is ideal for a broad range of redox applications, including:
• Water Treatment: Monitoring ozone systems, water purification, drinking water quality, and water pollution monitoring.
• Industrial Processes: Applications such as Chromate reduction, Cyanide oxidation, and Pulp bleaching.
• Environmental Monitoring: Checking free chlorine activity (e.g., in pools, spas, and cooling waters) and aquaculture.
