Model 1010 Microprocessor pH Meter:
The Model 1010 Microprocessor pH System is a sophisticated, solid-state instrument engineered to provide precise measurements of pH, mV, and temperature. Utilizing the latest microprocessor technology and advanced engineering techniques, the system ensures enhanced accuracy and reproducibility for a wide range of analytical tasks.
Core Features and Technology:
This benchtop pH meter is designed for straightforward operation while offering professional-grade results.
• Multi-Parameter Measurement: Capable of measuring pH, mV, and Temperature.
• Microprocessor Control: The solid-state instrument uses a microprocessor-based design for stable and reliable performance.
• Enhanced Accuracy: Designed to be highly accurate and easy to operate.
• Intuitive Keypad: The system features 6 soft touch membrane type keys for operational ease.
• Durable Calibration: Calibration settings are retained even after the instrument is switched OFF.
Advanced Calibration Capabilities:
The Model 1010 simplifies crucial calibration procedures to ensure reliable results across the measurement range.
• Automatic Calibration: Supports auto 2 or 3 points buffer calibration.
• Auto Buffer Recognition: Includes automatic recognition for standard pH buffers: 4.00, 7.00, and 9.20 pH.
• Automatic Temperature Compensation (ATC): Features an auto temperature compensation facility (0 to 100°C range) which automatically corrects pH readings for variations in sample temperature, providing accurate results.
Display and Design:
• Clear Readout: Measurements are displayed on a 7-Segment Bright Red LED display, featuring 4 digits dedicated to pH/mV readings and 3 digits for Temperature.
• Temperature Sensor: Utilizes a Semi-Conductor sensor for accurate temperature monitoring.
Applications
The Model 1010 Microprocessor pH System is extremely useful in professional, industrial, and academic environments where water and solution quality control is critical. Typical areas of application include:
• Agricultural and soil analysis laboratories
• Water quality control in boiler feed water and water works departments
• Fertilizer plants and petroleum refineries
• Breweries and water purification plants
• Swimming pools
Technical Specifications:
|
Parameter
|
Specification
|
|
Model Number
|
1010
|
|
Type
|
Microprocessor pH Meter
|
|
Parameters Measured
|
pH, mV, Temperature
|
|
pH Range
|
-2 to 20.00 pH
|
|
pH Resolution
|
0.01 pH
|
|
pH Accuracy
|
± 0.01, ± 1 Digit (or ±0.02 pH)
|
|
mV Range
|
0 – ±1999 mV
|
|
mV Resolution
|
1 mV
|
|
mV Accuracy
|
± 1 mV, ± 1 Digit
|
|
Temperature Range
|
-5 to 110°C
|
|
Temperature Resolution
|
0.1 °C
|
|
Temperature Accuracy
|
± 0.1 °C (Note: Some sources indicate ±1°C)
|
|
Calibration
|
Auto (2 or 3 point)
|
|
Auto Buffer Recognition
|
4.00, 7.00 & 9.20 pH
|
|
Temperature Compensation
|
0 to 100°C Auto/Manual
|
|
Temperature Sensor
|
Semi-Conductor
|
|
Relative Stability
|
0.02 pH/Hour
|
|
Acceptable Electrode Slope
|
80% – 120%
|
|
Readout Display
|
7-Segment Bright Red LED display (3 for Temperature and 4 for pH/mV)
|
|
Key Board
|
6 Keys, Soft Touch Membrane Type
|
|
Power Supply
|
12V DC, using 230V ± 10% AC Adapter (Note: Some models use 230V ± 10% AC, 50 Hz directly)
|
|
Dimensions (Approx.)
|
280 X 190 X 90 mm (or 270 x 202 x 80mm)
|
|
Weight (Approx.)
|
0.8 Kg. (Note: Some sources indicate 3.5 Kg.)
|
|
Accessories Included
|
Combination pH Electrode, Buffer Tablets (7.0 and 4.0 pH), Temperature Probe, Electrode Stand, 12V Adaptor (or Mains Lead), Operation Manual and Dust Cover
|
|
Country of Origin
|
India
|
