Sartorius MA160 Moisture Analyzer
Sartorius MA160 Moisture Analyzer: Advanced Solution for Sophisticated Moisture Analysis
The Sartorius MA160 is a high-performance moisture analyzer designed for professionals who require maximum flexibility and reliability for analyzing diverse sample types. Using the thermogravimetric method, this innovative instrument accurately determines moisture content in liquids, pastes, and solids with outstanding speed and reproducibility. The MA160 features an intuitive Method Development Assistant that creates new testing protocols in just three easy steps, comprehensive method management, and a built-in performance verification system.Key Features & Benefits Sartorius MA160 Moisture Analyzer
- High-Speed Measurements - Optimized AURI heating unit and chamber geometry deliver up to 30% faster analysis times
- Exceptional Method Development - Integrated Assistant function creates new testing protocols in three simple steps
- Extensive Memory Capacity - Store up to 100 different methods and the last 999 measurement results
- User-Friendly Interface - Intuitive touchscreen with clear menu prompts for effortless operation
- Visual Status Indication - Integrated light displays current measurement progress at a glance
- Quick Performance Testing - ReproEasy Pad enables complete system verification in just 5 minutes
- Legacy Compatibility - Supports method parameters from Sartorius MA150 and MA35 analyzers
- BetterClean Design - Removable components for easy cleaning, even in laboratory washers
- Advanced Data Transfer - SD card functionality for importing/exporting methods and results
- Comprehensive Connectivity - Mini USB port with automatic printer detection and Microsoft® Office integration
Technical Specifications Sartorius MA160 Moisture Analyzer
| Specification | Details |
|---|---|
| Maximum Weighing Capacity | 200 g |
| Reproducibility (Typical) | ±0.2% (from approx. 1 g initial sample weight) ±0.05% (from approx. 5 g initial sample weight) |
| Readability | 1 mg, 0.01% |
| Typical Sample Quantity | 5 g - 15 g |
| Display Modes | - Moisture content in % M and % g - Dry weight in % S and g - ATRO (ratio) in % M/S |
| Temperature Range | 40°C - 200°C (in 1°C increments) |
| Standby Temperature | Selectable from 50°C - 120°C |
| Heating Technology | Infrared heating using an AURI heating unit, 600 W |
| Heating Programs | Standard drying, gentle drying, MA35 mode |
| Shutoff Parameters | Fully automatic, semi-automatic, manual, and timer settings |
| Data Interface | Mini USB port; automatic printer detection; direct transfer to Microsoft® Office |
| Data Transfer | SD card; function for importing and exporting methods and results |
| Dimensions (W × D × H) | 215 × 400 × 210 mm (8.5" × 15.7" × 8.3") |
| Weight | Approx. 6.2 kg (approx. 13.6 lbs.) |
Innovative Technology
Advanced AURI Heating Unit Sartorius MA160 Moisture Analyzer
The MA160 features a state-of-the-art AURI (Advanced Uniform Radiant Infrared) heating system that delivers significant advantages:- Accelerated Analysis - Powerful 600W heating capacity reduces measurement times by up to 30%
- Uniform Sample Drying - Optimized chamber geometry ensures consistent heat distribution
- Precise Temperature Control - 1°C increments from 40°C to 200°C for optimal method development
- Multiple Heating Programs - Choose between standard drying, gentle drying, or MA35 mode based on sample requirements
- Energy Efficiency - Advanced design maximizes heat transfer while minimizing power consumption
- Standby Temperature Option - Selectable from 50°C to 120°C to minimize warmup time between measurements
Method Development Assistant Sartorius MA160 Moisture Analyzer
The innovative Method Development Assistant solves the time-consuming challenge of determining optimal testing parameters:- Three-Step Process - Create new methods quickly and easily without specialized training
- Parameter Optimization - Automatically determines ideal temperature, heating program, and shutoff criteria
- Method Library - Efficiently organize up to 100 custom methods for different products
- Method Transfer - SD card functionality allows sharing methods between multiple MA160 units
- Legacy Compatibility - Supports parameters from MA150 and MA35 analyzers for simplified upgrades
Comprehensive Data Management Sartorius MA160 Moisture Analyzer
The MA160 delivers advanced features for GMP-compliant documentation and data handling:- Extended Result Storage - Automatically saves the last 999 measurements for complete traceability
- SD Card Functionality - Import and export methods and results for backup and sharing
- Direct Office Integration - Transfer data seamlessly to Microsoft® Office applications
- Multiple Printer Options - Automatic printer detection with support for various printer models
- GMP Compliance - Complete documentation capabilities support regulatory requirements
Applications & Industry Use
Versatile Sample Analysis Sartorius MA160 Moisture Analyzer
The MA160 is engineered to handle diverse sample types across multiple industries:- Food & Beverage - Analyze moisture content in ingredients, intermediates, and finished products
- Pharmaceuticals - Test raw materials, excipients, and final formulations
- Chemicals - Determine moisture levels in powders, granulates, and liquid formulations
- Paper & Packaging - Verify moisture specifications in pulp, paper, and packaging materials
- Environmental - Test soil samples, waste materials, and environmental specimens
Sample Handling Flexibility Sartorius MA160 Moisture Analyzer
The comprehensive 200g capacity and accessory options support various sample types:- Solid Materials - Direct analysis using standard aluminum sample pans
- Pasty & Fatty Samples - Effective testing using hard quality glass fiber pads
- Liquids - Accurate analysis with soft quality glass fiber pads for optimal absorption
- Small Quantity Samples - Precise results with initial sample weights as low as 1g
- Heat-Sensitive Materials - Gentle drying program preserves sample integrity
Quality Control Applications Sartorius MA160 Moisture Analyzer
- Incoming Material Inspection - Verify moisture specifications for raw materials
- In-Process Control - Monitor moisture content during production
- Final Product Testing - Ensure finished products meet moisture requirements
- Stability Studies - Track moisture changes over time under controlled conditions
- Method Validation - Develop and validate moisture testing protocols
User-Friendly Operation Sartorius MA160 Moisture Analyzer
Intuitive Interface Sartorius MA160 Moisture Analyzer
The MA160 prioritizes ease of use with an intuitive design approach:- Touch Screen Display - Clear, responsive interface for effortless navigation
- Guided Workflow - Easy-to-understand menu prompts guide users through operations
-
Status Light Indicator - Visual progress tracking with clear status indications:
- "running | START" - Measurement in progress
- "analysis completed | STOP" - Test complete
- "analyzer OFF" - System standby
- "error" - Attention required
- Multiple Result Formats - View data in the most relevant format for your application
- Sample Handling Tools - Included forceps for easy placement and removal of sample pans
BetterClean Design Sartorius MA160 Moisture Analyzer
The innovative construction significantly simplifies maintenance and cleaning:- Removable Components - Heating unit and sample chamber plate can be completely detached
- Laboratory Washer Compatible - Key parts can be safely cleaned in standard laboratory washers
- Easy-Access Chamber - Optimized design facilitates thorough cleaning
- Contamination Prevention - Design minimizes sample residue buildup
Performance Verification Sartorius MA160 Moisture Analyzer
The MA160 features a comprehensive built-in performance testing system:- ReproEasy Pad Technology - Specialized test pads with precisely defined moisture content
- 5-Minute Verification - Complete system check performed in minimal time
- Comprehensive Testing - Verifies both heating unit and weighing system functionality
- Simple Procedure - One-touch operation initiates the entire verification process
- Documentation - Test results can be stored and printed for compliance records
Available Accessories Sartorius MA160 Moisture Analyzer
| Part Number | Description |
|---|---|
| 6965542 | Disposable sample pans, 80 units, aluminum, ∅ 90 mm |
| 6906940 | Glass fiber pads for analysis of pasty and fatty samples, hard quality; 80 units; ∅ 90 mm |
| 6906941 | Glass fiber pads for analysis of liquid and fatty samples, soft quality; 200 units; ∅ 90 mm |
| YHP01MA | ReproEasy pads, 10 units for performance testing to check the functionality of the analyzer's heating unit and weighing system |
| YCW512-AC-02 | External calibration weight, 100 g (E2) with DAkkS calibration certificate |
| YDP40 | Standard laboratory printer |
| YDP30 | Premium GLP laboratory printer |
| YCC03-D09 | Adapter cable for connecting the YDP20-OCE printer |
| YDP20-0CE | Data printer |
| YST01MA | Forceps for samples |
| YMD02B | Customer-specific service for individual method development for the MA160 at the Sartorius Application Laboratory (includes short report) |
Professional Support Services Sartorius MA160 Moisture Analyzer
Method Development Service
For laboratories requiring specialized expertise, Sartorius offers comprehensive method development support:- Custom Method Creation (YMD02B) - Expert assistance from Sartorius Application Laboratories in Germany or the USA
- Personalized Protocols - Methods optimized for your specific samples and requirements
- Technical Documentation - Includes detailed report with parameter recommendations
- Implementation Support - Guidance on implementing new methods in your workflow
Technical Support Sartorius MA160 Moisture Analyzer
Sartorius provides comprehensive support to ensure optimal performance of your MA160:- Installation Assistance - Professional setup and initial training
- Method Transfer - Support for migrating from previous models
- Calibration Services - Regular verification of analyzer accuracy
- Performance Qualification - Documentation for regulatory compliance
- Ongoing Technical Support - Expert assistance throughout the analyzer's lifecycle
Operational Workflow
Method Development Process Sartorius MA160 Moisture Analyzer
- Sample Selection - Choose a representative sample for analysis
- Launch Assistant - Activate the Method Development Assistant function
- Initial Setup - Enter basic parameters and follow the guided workflow
- Automatic Optimization - MA160 determines ideal temperature, heating program, and shutoff criteria
- Method Verification - Confirm results with additional samples
- Method Storage - Save the optimized method in the library with a descriptive name
- Optional SD Backup - Transfer the method to SD card for sharing or backup
Routine Sample Analysis Sartorius MA160 Moisture Analyzer
- Method Selection - Choose the appropriate method from the library
- Sample Preparation - Prepare sample according to established protocol
- Sample Loading - Place sample pan on the weighing pan and distribute sample evenly
- Measurement Initiation - Close chamber to automatically start analysis
- Progress Monitoring - Track status via the integrated status light
- Result Documentation - Review, store, print, or export results as needed
Performance Verification Sartorius MA160 Moisture Analyzer
- ReproEasy Pad Preparation - Remove a test pad from the package
- Test Initiation - Activate the built-in performance test function
- Pad Placement - Place the ReproEasy pad on the sample pan when prompted
- Automated Testing - Allow the system to complete the 5-minute verification process
- Result Review - Confirm system is functioning within specifications
- Documentation - Record results for compliance purposes if required
Advantages Over Competitive Systems Sartorius MA160 Moisture Analyzer
- Superior Speed - Up to 30% faster analysis times compared to conventional moisture analyzers
- Method Development Simplification - Three-step assistant eliminates complex parameter determination
- Extensive Memory - Store up to 100 methods and 999 results (significantly more than most competitors)
- Enhanced Data Mobility - SD card functionality for simple method and result transfer
- Quick Performance Verification - Complete system check in just 5 minutes
- High Capacity (200g) - Accommodates larger samples for improved representation
- Superior Reproducibility - ±0.05% for 5g samples ensures consistent results
- Legacy Compatibility - Supports method parameters from previous Sartorius models
- Comprehensive Connectivity - Direct Microsoft Office integration and multiple printer options
About Sartorius Sartorius MA160 Moisture Analyzer
Sartorius is a leading international partner of life science research and the biopharmaceutical industry. With innovative laboratory instruments and consumables, the company's Lab Products & Services Division concentrates on serving the needs of laboratories performing research and quality control at pharmaceutical and biopharmaceutical companies and academic research institutes. With manufacturing facilities in Germany and the United States, Sartorius produces high-quality laboratory instruments including balances, moisture analyzers, pipettes, and filtration systems that are recognized worldwide for their precision, reliability, and innovative design.Summary Sartorius MA160 Moisture Analyzer
The Sartorius MA160 Moisture Analyzer represents a significant advancement in moisture analysis technology, delivering the perfect combination of speed, accuracy, and usability for sophisticated laboratory applications. With its innovative Method Development Assistant, high-performance AURI heating unit, and comprehensive data management capabilities, the MA160 simplifies complex moisture analysis tasks while ensuring reliable, reproducible results. Key innovations include the accelerated drying technology that reduces analysis times by up to 30%, the intuitive three-step method development process, extensive memory capacity for 100 methods and 999 results, and versatile connectivity options including SD card functionality and direct Microsoft Office integration. The built-in performance verification system using ReproEasy pads provides confidence in measurement accuracy, while the BetterClean design ensures simple maintenance. With its 200g capacity, exceptional reproducibility (±0.05% for samples ≥5g), and versatile configuration options, the MA160 delivers professional-grade performance for moisture analysis across diverse sample types in food, pharmaceutical, chemical, and environmental testing applications. The combination of advanced technology, user-friendly design, and comprehensive support services makes the MA160 the ideal solution for laboratories requiring reliable, high-performance moisture analysis capabilities.Product overview
