Saffron High Precision Balance SES202S (200g x 0.01g)
The Saffron SES202S is a high-precision, load cell base balance engineered for superior performance and dependability in laboratory and industrial environments. This model is built to provide rapid and accurate weighing results, featuring a fast stabilization time and high resolution suitable for sensitive analytical work. Its space-saving design ensures it integrates easily into busy lab spaces, while comprehensive protection features guarantee longevity and reliability.
Key Performance and Safety Features
Precision and Stability: The SES202S utilizes an environmentally protected load cell that is temperature compensated, ensuring high stability and improved repeatability across various operating conditions. It boasts a high resolution exceeding 1,000,000 stable counts, critical for achieving reproducible results. An integrated anti-vibration feature further enhances weighing accuracy.
Ease of Use and Calibration: The balance features an advanced eye protected Backlit LCD with high contrast and enlarged characters, making results easier to read, even from a distance. The unit supports multi weighing units and includes a High/Low indication feature. Calibration is straightforward, utilizing an auto external calibration system.
Robust Design and Protection: Designed for safety and continuous operation, the SES202S offers a safe overload protection of 120% of FS (Full Scale) and ultimate overload protection of 150% of FS. For applications requiring precision in challenging conditions, an interior wind shield is available. For portable or remote operations, an inbuilt rechargeable battery backup is optionally available to ensure continuous use.
Technical Specifications
|
Feature
|
SES202S Specification
|
|
Max Capacity
|
200 g
|
|
Readability (d)
|
0.01 g
|
|
Repeatability
|
± 0.01 g
|
|
Linearity
|
± 0.02 g
|
|
Pan Size
|
120 mm Ø
|
|
Calibration
|
External auto Adjustment
|
|
Stabilization Time
|
2 ~ 3 seconds
|
|
Display
|
LCD (Backlit), full
|
|
Tare Range
|
full
|
|
Working Temperature
|
+5°C ~ +40°C
|
|
Relative Air Humidity
|
40% ~ 80%
|
|
Sensitivity Drift
|
2 ppm/°C
|
|
Interface
|
RS-232
|
|
AC Power Requirement
|
100 - 240V ± 20%
|
|
DC Power Supply
|
12V
|
|
Frequency
|
(50 - 60) Hz
|
|
Housing Material
|
ABS
|
|
Dimensions (L x W x H)
|
275 mm x 185 mm x 70 mm
|
|
Approximate Weight
|
2 kg Approx
|
|
Verification Accuracy (e)
|
2 mg
|
