Remi Direct Drive Stirrer – Model RQ-134 H/D:
The Remi RQ-134 H/D is a high-performance Direct Drive Stirrer designed specifically for demanding laboratory and small-scale industrial mixing applications. As a heavy-duty model, it is engineered to handle substantial volumes and provide consistent, powerful stirring across a wide speed range.
Key Features and Overview:
This stirrer is classified as a heavy-duty unit, making it an essential piece of laboratory equipment for processes requiring robust mixing capabilities. It features a powerful AC/DC motor capable of achieving high speeds, ensuring efficient and homogeneous mixing of fluids. The model RQ-134 H/D is an ideal choice for laboratories needing to process large batches up to 80 litres.
Performance and Capacity:
The RQ-134 H/D utilizes a direct drive mechanism, offering stable performance and high torque suitable for handling water and low-viscosity liquids. The stirring speed can be adjusted electronically within a broad range, typically from 500 RPM up to a maximum of 5000 RPM, allowing operators precise control over the mixing process. The powerful AC/DC motor, listed at 2/3 HP, ensures reliability even under continuous operation. This model is generally suitable for use with aqueous solutions.
Design and Construction:
The unit features robust construction to withstand continuous use in demanding laboratory environments. The stirring mechanism includes a durable stainless steel stirring shaft with a standard diameter and length, providing ample reach into large containers. The stirring is powered by a specialized impeller configuration designed for efficient fluid movement at high capacities.
Important Note: The RQ-134 H/D model uses an analogue speed control and does not feature a digital speed indicator.
Technical Specifications (Model RQ-134 H/D):
|
Feature
|
Specification
|
|
Product Type
|
Direct Drive Stirrer
|
|
Model Number
|
RQ-134 H/D
|
|
Brand
|
Remi
|
|
Max. Stirring Capacity
|
80 Litres (Ltrs.)
|
|
Stirring Fluid Type
|
Water
|
|
Motor Type
|
AC/DC Motor
|
|
Motor Power
|
2/3 HP (or 1/3 HP, depending on specific configuration)
|
|
Minimum Speed (RPM)
|
500 RPM (or 900 RPM)
|
|
Maximum Speed (RPM)
|
5000 RPM
|
|
Digital Speed Indicator
|
No
|
|
Stirring Shaft Diameter
|
12 mm
|
|
Stirring Shaft Length
|
450 mm
|
|
Impeller Type
|
Pitched Fan x 2
|
|
Impeller Diameter
|
75 mm
|
|
Common/Generic Name
|
Stirrer
|
|
Country of Origin
|
India
|
|
Dimensions (LxWxH)
|
93 x 35 x 25 cm (Approximate)
|
|
Weight
|
28 kg (Approximate)
|
